Product Description

Computerized Universal Testing Machine

Technical Specification

Machine consists of:
Straining Unit
Control Panel Power Pack
Hydraulic Controls
Automatic Continuous Roll Load – Elongation Recorder
Load Indicator System
Software Features:
Test you can conduct:
Tensile Test
Proof Test [Stress Vs %Strain (If Extensometer is used)]
Compression Test Bend Test
Single Shear
Double Shear
Some Data Entry Points :
Pre – Load Data Entry to avoid slippage in graph
Fully customized data entry
Extensometer Gauge Length Selection – 10, 25, 50 mm
Lower force & higher force data entry in % of maximum load to calculate proof stress
Real time Graphs :
Dual Graph – Stress Vs %Strain and Load Vs Displacement (If Extensometer is used)
Load Vs Displacement
Specimen Types :
Round
Flat Hollow
TOR / TMT Steel
Units :
Load – kN, Kg, N
Stress – kN/mm2, N/mm2 (MPa), Kg/mm2
Displacement – mm
Before start test you will get all information entered regarding test.
Fully customized header & footer information for test report.
Facilities to search, open, view, delete previously tested files.
Results Parameters : * Ultimate Load, Ultimate Strength, Displacement at Ultimate Load, Maximum Displacement, %Elongation, %Reduction in area, Breaking Load, Breaking Stress, Yield Load, Yield Strength, 0.02% Proof Strength, 0.1% Proof Strength, 0.2% Proof Strength, 0.5% Proof Strength,, 1% Proof Strength, all Proof loads, Young’s Modulus.
