Product Code: VELOCITY-EQP40-4200002
Categories: Bitumen and Asphalt Testing Lab Equipment
Refrigerated Ductility Test System for supply in Lab Brazil, TVET Mexico, TVET Colombia, Lab Argentina, Peru, Lab Venezuela, TVET Chile, Ecuador Lab Exporters, Guatemala, Cuba, Haiti, Bolivia, Dominican Republic, Lab Honduras, Refrigerated Ductility Test System TVET Lab Paraguay, El Salvador, Nicaragua, Costa Rica, Puerto Rico, Panama, Uruguay Lab Suppliers, Algeria, Refrigerated Ductility Test System Egypt, Morocco, Tunisia, Burundi, Comoros, Djibouti, Eritrea, Ethiopia, Exporters Kenya, Madagascar, Malawi, Mauritius, Mayotte, Suppliers Mozambique, Rwanda, Somalia, Lab Uganda, Refrigerated Ductility Test System Tanzania, Zambia, Lab Zimbabwe, Angola, Cameroon, Lab Central African Republic, Chad, Lab Congo, Botswana, Lesotho, Namibia, Lab South Africa, Swaziland, Benin, Refrigerated Ductility Test System Gambia, Lab Ghana, Guinea, Guinea-Bissau, Liberia, Mali, Mauritania, Niger, Nigeria, Lab Senegal, Refrigerated Ductility Test System Sierra Leone, Togo Suppliers
Refrigerated Ductility Test System
One half of the briquette moulds is fixed in a fixed plate in the water bath, the other half of the briquette mould is fixed to a carrier which slides over a rotating threaded shaft with a clutch, the motor and gears to rotate the shaft are housed in a cabinet fixed above the other end of the bath.
A pointer fixed to the carrier moves over.
A scale graduated from 0-100 cm x 1mm fixed on the bath with “0” (zero) of the scale towards the fixed plates side.
The rotating shaft has 2 speeds of travel for the bracket, 5 cm/min. And 1cm/min.
Selected by a clutch.
Water bath inside is of stainless steel with insulation and water drain cock.
A heater with is fitted inside the water bath.
The temperature is controlled by dual display microprocessor based auto tuning PID digital temp. Indicator cum controller.
Control switches for motor, stirrer, heater and indicator lamps are fixed at a convenient place on the water bath.
Complete with three briquette moulds and one base plate, all supply single phase.
As per IS 1208.
