Bernoulli Theorem Demonstration Module
Venturi section machined from clear acrylic.
Eight static pressure tapping’s plus a total head measurement.
Flow control valve.
Manometer board with eight tubes.
Quick-release fitting for easy connection to Hydraulics Bench.
Determination of the exact section in Venturi tube.
Demonstration of Bernoulli’s Theorem.
Divergent convergent Position.
Determination of Bernoulli’s Theorem equation.
Convergent-divergent position.
Observation of differences between convergent and Divergent position.
SPECIFICATION:
Manometer range: 0 to 300 mm of water.
Number of manometer tubes: 8.
Anodized aluminum/ MS powder coated structure and panel of painted steel.
Dimensions: 800 x 450 x 700 mm. approx.
Upstream diameter of the throat: 25 mm.
Easy and quick coupling system built-in.
Weight: 15 Kg. approx. (33 pounds approx.)
Hydraulics Bench or Basic Hydraulic Feed System.
Narrowing:
Downstream: 21°.
Upstream: 10°.
