Automatic Digital Compression Testing Machine

Automatic Digital Compression Testing Machine

The Main Characteristics are:

High stability welded assembly
Distance pieces and safety door included
Ball seating assembly and frame tested for stability
50 mm piston stroke with safety limit switch
Platen hardness of min 55 HRC

Data Acquisition And Control System:
Lcd graphics data acquisition and controls system is designed to control the Automatic digital compression testing machine and processing of data from load cells or pressure transducers installed on the compression machine frame.
Contained in light alloy housing and its design satisfies the ergonomic requirements for various use.
The digital graphic display allows real time load vs time graph.
The easy to read lcd graphic display and touch-button data pad keys make the unit quick and straight forward to operate.
All interactions with the measuring system are via the front control panel by using simple menu-driven procedures.
At the end of the test cycle, the results can be stored in the large memory or downloaded to a PC in software format.
Dedicated software package is available for further online data processing, database management and certificate printing.

The Main Characteristics are:
High resolution 65.000 points
240 x 120 pixel blue-white graphic lcd display
Standalone full automatic testing capacity
CPU card by microprocessor 32 bit arm risk architecture
Can make manual tests if required
A sample type and dimensions can be entered respect to the standard
18 key touch membrane keyboard
Easy to operate with 6 main function keys
Large permanent memory up to 256 test results
Rs232c (optional ethernet) connection at 57600 band
One RS232 serial port for connecting either PC or printer for data transmission
Two analogical channels, use for load cell or pressure transduce
Can control two frames (Compression & Flexural)

Power Pack:
Dual stage power pack which is controlled by is designed to supply required oil to the frames.
Very silent Power pack can load a specimen between 1 kn/ sec to 20 kN/sec.
On the dual stage pump high delivery low pressure pump is used for rapid approach and low delivery high pressure radial piston pump is used for test execution.
On all power packs maximum pressure valve is used to avoid machine overloading.

The Main Characteristics are:
Dual stage pump
750 W power
25 liter oil capacity
60-100 mm/min fast approach speed

Safety Features:
All Automatic digital compression testing machine are fitted with:
Max pressure valve to avoid machine overloading
Ram travel switch to prevent excessive piston travel
Front and rear gates with transparent durable flexiglass
Emergency stop button
Software controlled maximum load value
